Custom Made Copper Clad Printed Circuit Board , Power Amplifier PCB 8 Layers 1.0mm

Name: Custom Made Copper Clad Printed Circuit Board Power Amplifier PCB 8 Layers 10mm
Brand: LEFANG
Price: 1 USD

Buy cheap Custom Made Copper Clad Printed Circuit Board , Power Amplifier PCB 8 Layers 1.0mm product

Brand Name : LEFANG

Model Number : OT6008L365

Certification : ISO9001, ISO14001, ISO/TS16949, SGS, UL, RoHs,OHSAS18000

Place of Origin : Shenzhen,China

MOQ : 1 Piece

Price : Negotiable

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 290, 000sqm Per Month

Delivery Time : 2-10 work days

Packaging Details : Inner: Vacuum Packing; Dry Packing out Packing

Base Material/ Dielectric : fr - 4

Layer : 8 Layers

Surface treatment : Immersion gold

Board thickness : 1.0 mm

Solder Mask : blue

Min. Aperture : 0.1 mm

Line Width/Spacing : 0.1 / 0.075 mm

Size : 40 * 90 mm

Copper Thickness : 70 um / 2 OZ

Contact Now

8 Layers 1.0mm ENIG Blue Solder Heavy Copper PCB Printed Circuit Board

The 8 layers thick copper PCB Board is made with FR4 Board material with 2 Oz / 70 µm copper thickness. Also, the board size of this high frequency PCB Board is 40 * 90 mm, with blue solder mask and OSP surface treatment.

Custom Made Copper Clad Printed Circuit Board , Power Amplifier PCB 8 Layers 1.0mm

How to get quick quotation?

Step 1 Please send us Gerber file with these format: .CAD / .Gerber / .PCB / .DXP / .P-CAD, etc

Step 2 Also please provide us the below details for quick quotation:

Board material: Fr - 4 / CEM - 1 / CEM - 3 / 22F / Fr - 1 / others

Material brand: SY / KB / Rogers (optional)

Material Specification:High Tg / copper based / aluminum based or others (optional)

Board thickness: 0.1 - 6.0 mm

Copper thickness: 0.05 Oz - 8 Oz ( 17 um - 288 um )

Surface Treatment: OSP / ENIG / HASL / Lead Free HASL / Immersion Tin / Immersion Sin

Color of solder mask and silk print: Green / red / blue / black / white / yellow ,etc

Board size and quantity

If you don't have Gerber file, please provide us the imfomation as step 2 or post your PCB Board to us for clone.

SAMPLE:

Board Basic Info - SAMPLE
Board material	Fr - 4
Material brand	KB
Material Specification	Tg 170
Board thickness	1.6 mm
Copper thickness	1 Oz
Surface Treatment	ENIG
Solder mask / sSilk print	Green / White
Board size	100 mm * 100 mm
Quantity	10k

Technical Data

Item	Details
Max layer count	20 L
Max board thickness	6.0 mm
Max aspect ratio	10 : 1
Max copper thickness	6 OZ
Max dimension	600 * 700mm
Min thickness of 4 layers PCB	0.4 mm
Min hole / pad	0.15 / 0.35mm
Hole location accuracy	+ / - 0.05mm
PTH hole tolerance	+ / - 0.05mm
Min line width and line space	0.065 / 0.065mm
Surface treatment	HASL / HASL lead free, OSP Immersion gold/silver/tin, gold plating (hard gold and soft gold), silver plating, tin plating, platinum plating, carbon ink, ENEPIG (electroless nickel - electroless palladium - immersion gold)

Lead Time

Layer count	Sample lead time/workday	Batch lead time/workday
1-2L	2	6
4L	5	8
6L	5	9
8L	6	10
10L	8	10
12L	8	12
14L	10	15
16L	10	18
18-40L (Up to difficulty)	at least 18	at least 24
P.S. For HDI, Blind/Buried Hole PCB: Regular Lead Time + 3 workdays

Why you can trust our products?

-- What LEFANG's vision is to Make Our Customer's Products Better, so we try our best to fulfill the quality control

system andenvironmental management system. Our approved certification are as below:

ISO9001:2008	ISO14001:2004
ISO/TS16949:2009	OHSAS18000
UL	RoHS
QC080000	CQC

Now send us your inquiry, and you will be replied within 8 hours!

Little knowledge - Multilayer PCB Board
Multilayer printed circuit boards (Multilayer PCBs) represented the next major evolution in fabrication technology.
A very sophisticated and complex methodology came from the base platform of double sided plated.
This methodology would again allow circuit board designers a dynamic range of interconnects and applications.
Multilayer PCB board were essential in the advancement of modern computing, and their basic construction and fabrication are similar to micro chip fabrication on a micro size.
The range of material combinations is extensive from basic epoxy glass to exotic ceramic fills, and it can be built on ceramic, copper, and aluminum. Also, blind and buried vias are commonly produced in multilayer pcb manufacturing, along with pad on via technology.
